Introduce

The container house uses sandwich insulation, heat insulation, structural moisture-proof and other technologies to ensure comfort and durability:

1. Insulation: The wall adopts polyurethane/rock wool sandwich panels (thermal conductivity as low as 0.022 W/(m·K)), and the floor adopts cement fiberboard. The temperature difference between indoor and outdoor in winter can reach more than 15℃.

2. Insulation: The metal plate reflects sunlight and reduces the surface temperature by 10℃~15℃; the awning or ventilation cavity design can be selected, and the indoor temperature is 8℃~12℃ lower than the outdoor temperature in summer.

3. Moisture-proof: The box is suspended to prevent ground moisture, and the joints are sealed with waterproof glue + rubber strips; the inner wall uses moisture-proof gypsum board, and the insulation layer is hydrophobic rock wool (water repellency ≥98%), and the humidity is controlled at ≤60% with the vents.

Adaptation to environments: thickening the insulation layer in high cold, adding a sunshade system at high temperature, and using galvanized anti-corrosion + mildew-proof coating in high humidity areas. The overall life can reach 10~20 years, taking into account fast installation and durability

Details

Standard configuration list of quick consolidation container
Parameters		Thermal insulation performance	λ=0.048W/m·K	Wind resistance	0.60kN/m²
		Sound insulation performance	Sound insulation ≥30dB	Fire performance	Level A
		Waterproof	There is organized drainage, with precipitation of 16mm/min and no leakage.	Shock resistance	Level 8
		Ground live load	2.0kN/㎡	Roof live load	1.0kN/㎡
External dimensions: L5950mmW3000mmH3000mm			Configuration Instructions	quantity	Remark
1	Main frame	Top frame	Top long beam: 2.3mm galvanized steel, top frame 160mm;	2
		Top frame	Top short beam: 2.3mm galvanized steel, top frame 160mm;	2
		Bottom frame	Bottom long beam: 2.3mm galvanized steel, top frame 160mm;	2
		Bottom frame	Bottom short beam: 2.3mm galvanized steel, top frame 160mm;	2
		Column	Column: 2.3mm galvanized steel 160mm*160mm;	4
		Column	Bolts: M12×35 high-strength bolts;	64
		Corner	160mm*160mm, wall thickness 4.0mm;	8
2	Spray paint	Electrostatic spraying technology, no fading for 7 years;		1 set
3	Platen slot	Top long beam pressure plate groove: aluminum alloy profile thickness 1.0mm;		2
3	Platen slot	Top short beam pressure plate groove: aluminum alloy profile thickness 1.0mm;		2
4	Square tube system	Chassis purlin	50*10 galvanized square tube, thickness 1.2mm;	9
		Top purlin	50*50 galvanized square tube, thickness 1.6mm;	2
			40*60 galvanized square tube, thickness 1.1mm;	1 piece	6.00m long
			40*60 galvanized square tube, thickness 1.1mm;	6	1.88m Length
		Door frame column	20*40 galvanized square tube, thickness 1.2mm;	1 piece
5	Rockwool wall panels		The color steel composite board is 50mm thick, the double-sided thickness of the color steel board is 0.25mm, PE film is attached, the color is white and gray, and the double-sided ribs are pressed; the rock wool bulk density is 60kg/m³, and the combustion performance is Class A non-combustible.	1 set
6	Steel door		Steel door set, size ≥W925mm×H2035mm, fireproof door lock;	1 fan
7	External windows		Plastic steel series sliding window, size: W920mm×H1200mm×2; single glass with anti-theft tube;	2 fans
8	Indoor floor		18mm cement sanding board	5 pieces
9	Roof Tile		The thickness of the color steel veneer is 0.45mm;	6 sheets
10	Roof insulation		Glass wool felt, thickness 40mm, bulk density 14kg/m³, combustion performance is Class A non-combustible;	1 volume
11	Indoor ceiling tiles		0.23mm single-layer color steel plate-98 type corrugated tile;	6 sheets
12	Interior decoration corner		Color steel inner corner line, 4 inner corners, 4 inner corners	1 set
13	Other auxiliary materials		Standard includes all screws, structural adhesives, etc.	1 set
14	Indoor circuit (optional) Please let me know if you need a circuit		Light: LED dustproof light × 2 sets, 40W/set	0 sets	Default surface mounted
			Socket: 10A five-hole socket × 4, 16A air conditioning socket × 1
			Switch: Single-button switch × 1
			Distribution box: Surface mounted distribution box × 1
			Wiring: Household line: 34 square, air conditioning socket: 32.5 square, five-hole socket: 3*1.5 square

35.952.8m Standard container house material list
No.	Item	Specification	unit	Qty	Length(m)	Notes
1	Wall	50mm Rock wool sandwich panels	pc	15	2.56	double-sided color steel thickness 0.3mm
1	Wall	50mm Rock wool sandwich panels	pc	1	3.18	double-sided color steel thickness 0.3mm
2	Main Frame	Top beam	pc	2	5.63	2.3mm cold-dip galvanized steel
		Top beam	pc	2	2.68
		Bottom beam	pc	2	5.63
		Bottom beam	pc	2	2.68
		Column	pc	4	2.48
		Plate slot	pc	2	5.7	1.0mm Thickness
		Plate slot	pc	2	2.8	1.0mm Thickness
		Comer connector	pc	8		4.0mm thickness
3	Galvanized steel tubes	Bottom purlin	pc	9	2.99	50*100mm Thickness 1.2mm
		Bottom purlin	pc	1	2.55	20*40 Thickness 1.2mm
		Top purlin	pc	2	2.8	50*50mm Thickness 1.5mm
			pc	3	1.88	40*80mm Thickness 1.1mm
			pc	6	1.88	40*60mm Thickness 1.1mm
4	Door frame tube		pc	1	2.55	20*40 Thickness 1.2mm
5	Electrostatic spraying		set	1		Painting on top&bottom beam &corner& column
6	Door		pc	1	925*2035	steel security door
7	Windows		pc	2	920*1200	white security window
8	Roof tiles		pc	6	2.95	0.45mm thickness
9	Ceiling tiles		pc	6	2.78	0.23mm Thickness
10	Floor		pc	5	2.8*1147	18mm thickness FR cement sanding board
11	Glass wool		Roll	1		40mm glass wool on top insulation
12	Comer fittings		set	1		Aluminium fitting fixed on the corners
13	Hardware&fittings		set	1		including screwsglues
